Specifications
1. Lifting height 40m, loading capacity 6t, long jib length 56 m
2.Factory supply, low price
3.Installation support
4.Good after-sales service
5. Mast section: 1.833x1.833x2.5m
Main Technical Parameters of QTZ63-5610Tower Crane
| Tower Crane (QTZ63 5610) Rated lifting torque | kN.m | 630 |
| Max. lifting capacity | t | 6 |
| Working range | m | 3-56 |
| Lifting Height | Independent | 40.2 |
| Adhered | 151.2 |
| Lifting speed | Double magnification | m/min | 80/40 |
| Quadruple magnification | 38/19 |
| Slewing speed | r/min | 0.637 |
| Trolleying speed | m/min | 44/22 |
| Climbing speed | 0.4 |
| Min. stable descending speed | <7 |
| Overall dimensions | Foundation frame | m | 8×8 |
| Overall height | Independent | 50.892 |
| Adhered | 160.892 |
| Jib end to the swiveling center | 56.17 |
| Balance tip to swiveling center | 12.39 |
| Total weight | Structure weight | Independent | t | 40.49 |
| Adhered | 80.87 |
| counterweight | 18.34 |
| Total motor capacity | kW | 41.52 |
| Allowed operating temperature | C | -20-+40 |
| Power supply parameters | 50Hz | -380V±10% |
The parts of Katop tower crane
Construction site of Katop tower crane
Delivering of Katop Tower Crane:
1.Short delivery time, normally within 30workdays;
2.All products will be well fixed;
3.More easy wear spare parts will be attached for free;
4.The transportation will be safe and stable;
The Services of Katop Factory
1.All of our machines will be with 1 year warranty after receipt
the destination port;
2.More easy ware spare parts will be attached for free;
3.Oversea service are available from us, our experts will help you
to install and adjust the tower crane
in your area;
4.Technology support for maintenance and maintenance spare parts
will be supplied in time;
Why Choose Our Factory?
1. Experience. More than 10 years of experience in manufacturing tower crane and
construction hoist, assured good quality.
2. Price. We supply factory direct price, will save your cost than buy from
distributors or other factories;
3.Excellent quality. All materials from famous plants to ensure the long time use and
safety, and we are one of the suppliers
of standard mast for XCMG.
4. Services. Professional service team can give powerful support for our
products. Engineers have more than 10 years'
experience in products and ready to solve all your problems.
5. Innovation. Technical and management innovation guarantee our quality to be in
top position in our industry.
Our Certification
With more than 10 years experience of producing construction hoist and tower crane , Shandong Katop Machinery can supply you the good products with excellent quality, reasonable price and good after-sale service.
