Brand Name : | Katop |
Certification : | CE, ISO9001 |
Model Number : | SC200/200 |
Delivery Time : | About 30-50workdays after receipt the deposit; |
Payment Terms : | 30%TT in deposit, the balance 70%TT before shipment or by LC at sight |
Supply Ability : | 60units/month |
Specifications
1. Max. Lifting Weight: 2t mast section: 0.65*0.65*1.508m/0.8*0.8*1.508m
2.Factory supply, low price
3.Installation support
4.Good after-sales service
Construction Lifter Elevators SC200/200
Type | Construction Lifter Elevators SC200/200 | |
Place of Origin | Jinan Shandong, China (Mainland) | |
Brand Name | YUANXIN | |
Model Number | SC200/200 | |
Drive Type | Hydraulic | |
Lift Mechanism | Lift Chain | |
Lift Drive / Actuation | Electric Motor | YZZ132M-4 |
Power 11*3*2kw | ||
Rated Loading Capacity | 2*2000kg | |
Rated passengers | 2*12 | |
Max. Lifting Height | 150m/300m | |
Maximum Lifting Weight | 2 ton per cage | |
Construction Hoist | Construction Hoist | |
Cage inner dimensions L*W*H | 3*1.5*2.45m/3*1.3*2.45m | |
Dimension of standard section | 0.65*0.65*1.508m/0.8*0.8*1.508m | |
Rating hoisting speed | 33/36 m/min | |
Gear reducer | center distance | 125mm |
transmission ratio | 1:16 | |
Safety device | form | incremental |
spead of action | 51.6m/min | |
braking torque | ≥3000N.m |
![]() |
